| Item Reference | 3KG29 |
|---|---|
| Brand | STA-KON |
| Weight (lb) | 0.1 |
| Length (in) | 2.3 |
| Width (in) | 1.2 |
| Height (in) | 2.9 |
| Harmonization Code | 8536904000 |
| Country of Origin | United States |
Female Disconnect Contact Finish Tin Contact Material Copper Insulation Color Blue Insulation Coverage Partial Coverage Insulation Material Nylon Maximum Operating Temperature 221 Degrees F Minimum Wire Size 16 AWG Maximum Wire Size 14 AWG Maximum Voltage 600 V Tab Thickness 0.02 in Tab Width 0.11 in Terminal Type Socket Termination Style Crimp UL 94 Flammability Rating Not Rated RoHS Compliant Yes Seam Style Overlapped Barrel Inside Diameter 0.086 in Barrel Size Long
