| Item Reference | 12G127 |
|---|---|
| Brand | APPLETON ELECTRIC |
| Weight (lb) | 4.6 |
| Length (in) | 12.2 |
| Width (in) | 5.5 |
| Height (in) | 4.8 |
| Harmonization Code | 8536694020 |
| Country of Origin | Mexico |
Plug Current Rating 100 A Hazardous Location Specification Class I Div 1 and 2 Group B C D Class II Div 1 and 2 Group F G Class III Div 1 and 2 Horsepower Rating 75 hp Housing Color Gray Number of Poles 4 Number of Wires 3 Phase Three Voltage Rating 600V AC Cap Type Screw-On Cap Connection Orientation Straight Face Diameter 2.47 in For Maximum Cable Diameter 1.906 in For Minimum Cable Diameter 0.875 in Grounding Grounded Grounding Style Style 2
