| Item Reference | 4Z292 |
|---|---|
| Brand | DAYTON |
| Weight (lb) | 24.1 |
| Length (in) | 10.4 |
| Width (in) | 9.4 |
| Height (in) | 9.2 |
| Harmonization Code | 8483405010 |
| Country of Origin | United States |
Speed Reducer Input Connection Type C-Face Gear Type Worm Output Shaft Type Keyed Maximum Output Speed 29 RPM Motor Frame Designation 56C Worm Center Distance 1.75 in Gear Ratio 60 1 Rotation CW/CCW Maximum Input Horsepower 0.3 hp Maximum Output Torque 415 in-lb Overhung Load Capacity 700 ft-lb Mounting Orientation Any Position Except Input Motor Shaft Up Housing Material Cast Iron Application Speed Reducer Bearing Type Ball Tapered Roller
