| Item Reference | 4VAG1 |
|---|---|
| Brand | DAYTON |
| Weight (lb) | 19 |
| Length (in) | 13 |
| Width (in) | 9.13 |
| Height (in) | 9.63 |
| Harmonization Code | 8501404040 |
| Country of Origin | Mexico |
Belt Drive Motor Single Phase Motor Design Split-Phase 1/3 HP Nameplate RPM 1 725 No of Speeds 1 Voltage 115/208-230V AC 6.6/3.1-3.3 Full Load Amps 48Y Frame 60 Hz Motor Service Factor 1.15 Motor Thermal Protection Auto Ins. Class B Max Ambient Temp 60 Degrees C Duty Cycle Continuous Motor Shaft Rotation CW/CCW Motor Enclosure Design Open Dripproof Motor Mounting Type Cradle Base Motor Mounting Position All Angle Motor Frame Material Rolled Steel Shaft Dia 1/2 in
Mfr 4VAG1BG
