Close-Coupled Pump Motor Body Dia 6.5 in Bolt Circle Dia 5 7/8 in CC Number CC003A Conduit Box Location Exterior Conduit Box Position F1 Duty Cycle Continuous Frame 145JMV Hz 60 Full Load Amps 7.6/3.8 HP 3 Includes Drip Cover Ins. Class F Inverter Rated Yes Inverter Rating 10 1 Variable Torque 2 1 Constant Torque Length Less Shaft 11 3/16 in Max Ambient Temp 40 Degrees C Motor Application Pump Motor Bearings Ball Motor Design 3-Phase
Mfr 145TTDR16305
| Item Reference | 52JA13 |
|---|---|
| Brand | MARATHON MOTORS |
| Weight (lb) | 47.55 |
| Length (in) | 19.6 |
| Width (in) | 11.5 |
| Height (in) | 10.9 |
| Harmonization Code | 8501524000 |
| Country of Origin | Mexico |
