| Item Reference | 490T71 |
|---|---|
| Brand | MARATHON MOTORS |
| Weight (lb) | 20.08 |
| Length (in) | 13.7 |
| Width (in) | 7.5 |
| Height (in) | 8.1 |
| Harmonization Code | 8501514040 |
| Country of Origin | Mexico |
Belt Drive Motor Three Phase Motor Design 3-Phase 3/4 HP Nameplate RPM 1 725 No of Speeds 1 Voltage 208-230/460V AC 3.3-3.0/1.50 Full Load Amps 56 Frame Usable @ 208V Yes Usable @ 200V No 60 Hz Motor Service Factor 1.25 Motor Thermal Protection Auto Ins. Class B Max Ambient Temp 40 Degrees C Duty Cycle Continuous Motor Shaft Rotation CW/CCW Motor Enclosure Design Open Dripproof Motor Mounting Type Cradle Base Motor Mounting Position Horizontal Motor Frame Material Steel
