Severe Duty Motor Three Phase Motor Design 3-Phase 15 HP Nameplate RPM 875 No of Speeds 1 Voltage 460V AC Full Load Amps 22.0 286T Frame Usable @ 208V No Usable @ 200V No Hz 60 Motor Service Factor 1.15 Max Ambient Temp 40 Degrees C Motor Thermal Protection None Duty Cycle Continuous Ins. Class F NEMA Design B Motor Enclosure Design Totally Enclosed Fan-Cooled Motor Shaft Rotation CW/CCW Motor Mounting Type Rigid Base Motor Mounting Position Horizontal Inverter Rated Yes
Mfr 286THFNA19101
| Item Reference | 19RV44 |
|---|---|
| Brand | MARATHON MOTORS |
| Weight (lb) | 326 |
| Length (in) | 35 |
| Width (in) | 26 |
| Height (in) | 24.51 |
| Harmonization Code | 8501524000 |
| Country of Origin | United States |
