| Item Reference | 46M721 |
|---|---|
| Brand | MARATHON MOTORS |
| Weight (lb) | 379 |
| Length (in) | 35 |
| Width (in) | 36 |
| Height (in) | 21.89 |
| Harmonization Code | 8501513040 |
| Country of Origin | United States |
Vector Motor Three Phase Motor Design 3-Phase 25 HP Nameplate RPM 1 770 No of Speeds 1 Voltage 575V AC Full Load Amps 24.8 284TC Frame Torque 74.2 ft-lb Max Speed 1 800 RPM Speed Range 1 000 1 Usable @ 208V No Usable @ 200V No 60 Hz Max Operating Frequency 120 Hz Motor Service Factor 1 Motor Thermal Protection None Ins. Class F Max Ambient Temp 40 Degrees C Duty Cycle Continuous NEMA Design A Motor Shaft Rotation CW/CCW
Mfr 284THTNA7036
