| Item Reference | 60PV05 |
|---|---|
| Brand | LEESON |
| Weight (lb) | 51 |
| Length (in) | 19.5 |
| Width (in) | 10.44 |
| Height (in) | 10.88 |
| Harmonization Code | 8501524000 |
| Country of Origin | China |
Washdown Motor Three Phase Motor Design 3-Phase 1 HP Nameplate RPM 3 450 No of Speeds 1 Voltage 208-230/460V AC Full Load Amps 2.9-2.6/1.30 143TC Frame Usable @ 208V Yes Usable @ 200V No 60/50 Hz Motor Service Factor 1.2 Motor Thermal Protection Manual Ins. Class F Max Ambient Temp 40 Degrees F Duty Cycle Continuous NEMA Design B Removable Base No Motor Shaft Rotation CW/CCW Motor Enclosure Design Totally Enclosed Fan-Cooled Motor Mounting Type Rigid Base
