Motor Body Dia 5.9 in Conduit Box Location Exterior Duty Cycle Continuous Frame 56J Hz 60 Full Load Amps 8.9/4.4-4.5 Height 8 5/8 in HP 1/2 Ins. Class B Inverter Rated No Length Less Shaft 8 5/16 in Max Ambient Temp 104 Degrees F Max SF Amps 10.0/5.1-5.0 A Motor Application Pump Motor Bearings Ball Motor Design Capacitor-Start Motor Efficiency Group Standard Efficient Motor Enclosure Design Open Dripproof Motor Frame Material Rolled Steel
Mfr EU0504
| Item Reference | 56JC09 |
|---|---|
| Brand | U.S. MOTORS |
| Weight (lb) | 29.1 |
| Length (in) | 15.32 |
| Width (in) | 8.25 |
| Height (in) | 11 |
| Harmonization Code | 8501404040 |
| Country of Origin | Mexico |
