Motor Body Dia 5.9 in Conduit Box Location Exterior Duty Cycle Continuous Frame 56J Hz 60/50 Full Load Amps 2.8-2.7/1.35 Full Load Amps @ 50Hz 2.8-2.7/1.35 A HP 3/4 HP @ 50Hz 3/4 Ins. Class B Inverter Rated No Length Less Shaft 9 5/16 in Max Ambient Temp 104 Degrees F Max SF Amps 3.7-3.6/1.8 A Motor Application Pump Motor Bearings Ball Motor Design 3-Phase Motor Efficiency Group Standard Efficient Motor Enclosure Design Totally Enclosed Fan-Cooled
Mfr EE515
| Item Reference | 56JC04 |
|---|---|
| Brand | U.S. MOTORS |
| Weight (lb) | 22 |
| Length (in) | 18.5 |
| Width (in) | 12 |
| Height (in) | 12 |
| Harmonization Code | 8501514040 |
| Country of Origin | Mexico |
