General Purpose Motor Single Phase Motor Design Capacitor-Start/Run 1 1/2 HP Nameplate RPM 1 770 No of Speeds 1 Voltage 115/208-230V AC Full Load Amps 15.2/8.2-7.6 56HC Frame Usable @ 208V No Usable @ 200V No Hz 60/50 Motor Service Factor 1.15 Max Ambient Temp 40 Degrees C Motor Thermal Protection None Duty Cycle Continuous Ins. Class B Motor Enclosure Design Totally Enclosed Fan-Cooled Motor Shaft Rotation CW/CCW Motor Mounting Type Rigid Base
Mfr 056B17F5305
| Item Reference | 19YU86 |
|---|---|
| Brand | MARATHON MOTORS |
| Weight (lb) | 40.13 |
| Length (in) | 16.5 |
| Width (in) | 10.8 |
| Height (in) | 9 |
| Harmonization Code | 8501406040 |
| Country of Origin | Mexico |
